SLG59M1545V - 2.5A Integrated Power Switch

Silego

📥 Download Datasheet

SLG59M1545V Datasheet Preview — Preview of SLG59M1545V PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	SLG59M1545V
Manufacturer	Silego
File Size	140.42 KB
Description	2.5A Integrated Power Switch
Datasheet	SLG59M1545V-Silego.pdf

SLG59M1545V Product details

Description

The SLG59M1545V is a 17 m 2.5 A single-channel power switch that is able to switch 0.85 to 5 V power rails.

Features

1.0 x 1.6 x 0.55 mm STDFN 8L package (2 fused pins for drain and 2 fused pins for source).
Logic level ON pin capable of supporting 0.85 V CMOS Logic.
User selectable ramp rate with external capacitor.
17 mRDSONwhile supporting 2.5 A.
Two Over Current Protection Modes.
Short Circuit Current Limit.
Active Current Limit.
Over Temperature Protection.
Pb-Free / Halogen-Free / RoHS compliant.
Operating Temper.
