PS9513 - 1Mbps OPEN COLLECTOR OUTPUT

Name: PS9513
SKU: PS9513-831984

California Eastern Labs

📥 Download Datasheet

PS9513 Datasheet Preview — Preview of PS9513 PDF

Datasheet Details

Part number	PS9513
Manufacturer	California Eastern Labs
File Size	1.02 MB
Description	1Mbps OPEN COLLECTOR OUTPUT
Datasheet	PS9513-CaliforniaEasternLabs.pdf

PS9513 Product details

Description

The PS9513, PS9513L1, PS9513L2 and PS9513L3 are optically coupled isolators containing a GaAlAs LED on the input side and a photo diode and a signal processing circuit on the output side on one chip.

Features

Long creepage distance (8 mm MIN. : PS9513L1, PS9513L2).
High common mode transient immunity (CM H, CML = 15 kV/ s MIN. ).
High-speed response (tPHL = 500 ns MAX. , tPLH = 750 ns MAX. ).
Maximum propagation delays (t PLH.
Pulse width distortion ( | tPHL.
Open collector output.
Ordering number of tape product : PS9513L2-E3 : 1 000 pcs/reel : PS9513L3-E3 : 1 000 pcs/reel.
Pb-Free product.
Safety standards.
UL a.
