APC77135 - Smartphone Application Quad AFE designed

Bel Fuse

The APC77135 by Bel Fuse is a Smartphone Application Quad AFE designed. Below is the official datasheet preview.

📥 Download Datasheet

APC77135 Smartphone Application Quad AFE designed by Bel Fuse - Datasheet Preview — Official preview page of the **APC77135** Smartphone Application Quad AFE designed datasheet (Bel Fuse).

Datasheet Details

Part number	APC77135
Manufacturer	Bel Fuse
File Size	189.92 KB
Description	Smartphone Application Quad AFE designed
Datasheet	APC77135_BelFuse.pdf
Additional preview pages of the APC77135 datasheet.

APC77135 Product details

Description

HPF TX BPF RX BPF Passband Freq 900kHz-8MHz 900kHz-8MHz 4MHz-8MHz Impedance 120 ohms 40 ohms 270 ohms BLOCK DIAGRAM 1K2 290R NC 1K2 Rx LINE 1 CMC HPF Hybrid Tx ATTEN.LINE DRIVER Tx LINE 2 CMC HPF Hybrid Rx ATTEN.Rx LINE 3 CMC HPF Hybrid Tx ATTEN.Tx CMC LINE 4 HPF Hybrid Rx ATTEN.PEB 22825 OCTAL_A PEB 22824 OCTAL_D APC 77135 Smartphone ©2003 Bel Fuse Inc.Specifications subject to change without notice.05.20.03 Bel Fuse Inc.206 Van Vorst Street, Jersey City, NJ 07302

Features

Transhybrid Loss >15dBmin Incorporates xDSL choke >35dBmin Miniature footprint for increased Line-card density.
Provides 1500Vrms isolation voltage www. DataSheet4U. com.
