STPS160U, STPS160A 1A power Schottky rectifier

STPS160U Description

STPS140 Datasheet 40 V, 1 A power Schottky rectifier Product status STPS140 Product summary Symbol Value IF(AV) 1A VRRM 40 V T j(max.) 150 °.
Single chip Schottky rectifiers suited to switched mode power supplies and high frequency DC to DC converters.

STPS160U Features

* Very small conduction losses
* Negligible switching losses
* Low forward voltage drop
* Surface mount miniature packages
* Avalanche rated

STPS160U Applications

* Reverse polarity protection
* Set-top box power supply
* TV power supply

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: STPS160U, STPS160A. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
STPS160U, STPS160A
Manufacturer
STMicroelectronics ↗
File Size
354.93 KB
Datasheet
STPS160A-STMicroelectronics.pdf
Description
1A power Schottky rectifier
Note
This datasheet PDF includes multiple part numbers: STPS160U, STPS160A.
Please refer to the document for exact specifications by model.
