DS3886A - BTL 9-Bit Latching Data Transceiver

National Semiconductor

Datasheet Details

Part number	DS3886A
Manufacturer	National Semiconductor
File Size	187.71 KB
Description	BTL 9-Bit Latching Data Transceiver
Datasheet	DS3886A_NationalSemiconductor.pdf

The DS3886A is a higher speed, lower power, pin compatible version of the DS3886. BTL) as specified in the IEEE 896.2 Futurebus+ specification.

n n n n n n n n n Fast propagation delay (3ns typ) 9-BIT BTL Latched Transceiver Driver incorporates edge triggered latches Receiver incorporates transparent latches Meets IEEE 1194.1 Standard on Backplane Transceiver Logic (BTL) Supports Live Insertion Glitch free Power-up/down protection Typically less than 5 pF Bus-port capacitance Low Bus-port voltage swing (typically 1V) at 80 mA © 1999 National Semiconductor Corporation DS011458 www. national. com Features (Continued) n Exceeds 2 KV ES.
