IL613, IL610 - (IL610 - IL614) Passive Input Digital Isolators

NVE

IL613 Datasheet Preview — This datasheet PDF includes multiple part numbers: IL613, IL610. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	IL613, IL610
Manufacturer	NVE
File Size	470.50 KB
Description	(IL610 - IL614) Passive Input Digital Isolators
Datasheet	IL610_NVE.pdf
Note	This datasheet PDF includes multiple part numbers: IL613, IL610. Please refer to the document for exact specifications by model.

IL613 Product details

Description

The IL600 series are isolated signal couplers with CMOS or open drain transistor outputs which can be used to replace opto-couplers in many standard isolation functions.

Features

40 Mbps Data Rate Very Wide Input Voltage Range Open Drain or CMOS Outputs Failsafe Output (Logic high output for zero coil current ) Output Enable 3.3 V or 5 V Power Supply 2500 VRMS Isolation (1 Minute) Low Power Dissipation -40°C to 85°C Temperature Range 20 kV/µs Typical Common Mode Rejection UL1577 & IEC61010 Approval (pending) Available in MSOP, SOIC, and PDIP Packages an.
