DSP56F807 - 56F807 16-bit Hybrid Processor

Motorola Inc

The DSP56F807 by Motorola Inc is a 56F807 16-bit Hybrid Processor. Below is the official datasheet preview.

📥 Download Datasheet

DSP56F807 56F807 16-bit Hybrid Processor by Motorola Inc - Datasheet Preview — Official preview page of the **DSP56F807** 56F807 16-bit Hybrid Processor datasheet (Motorola Inc).

Datasheet Details

Part number	DSP56F807
Manufacturer	Motorola Inc
File Size	1.10 MB
Description	56F807 16-bit Hybrid Processor
Datasheet	DSP56F807_MotorolaInc.pdf
Additional preview pages of the DSP56F807 datasheet.

DSP56F807 Product details

Description

Two dedicated General Purpose Quad Timers totaling six pins: Timer C with two pins and Timer D with four pins CAN 2.0 B Module with 2-pin port for transmit and receive Two Serial Communication Interfaces each with two pins (or four additional GPIO lines) Serial Peripheral Interface (SPI) with configurable 4-pin port (or four additional GPIO lines) Computer-Operating Properly (COP) Watchdog timer Two dedic

Features

1.1.1.
Digital Signal Processing Core Efficient 16-bit 56800 family hybrid controller engine with dual Harvard architecture As many as 40 Million Instructions Per Second (MIPS) at 80MHz core frequency Single-cycle 16 × 16-bit parallel Multiplier-Accumulator (MAC) Two 36-bit accumulators including extension bits 16-bit bidirectional barrel shifter Parallel instruction set with unique DSP addressing modes Hardware DO and REP loops Three internal ad.
