X-Class HiPerFETTM Power MOSFET
Preliminary Technical Information
IXFK90N60X IXFX90N60X
VDSS = ID25 =
RDS(on)
600V 90A 38m
N-Channel Enhancement Mode Avalanche Rated Fast Intrinsic Diode
TO-264P (IXFK)
Symbol VDSS VDGR VGSS VGSM ID25 IDM IA EAS PD dv/dt
TJ TJM Tstg TL TSOLD Md FC Weight
Test Conditions
Maximum Ratings
TJ = 25C to 150C TJ = 25C to 150C, RGS = 1M
Continuous Transient
600 V 600 V
30 V 40 V
TC = 25C TC = 25C, Pulse Width Limited by TJM TC = 25C TC = 25C TC = 25C IS IDM, VDD VDSS, TJ 150°C
90 200
45 3
1100
50
-55 ... +150 150
-55 ... +150
A A
A J
W
V/ns
C C C
Maximum Lead Temperature for Soldering
300 °C
Plastic Body for 10s
260 °C
Mounting Torque (TO-264) Mounting Force (PLUS247)
1.13/10 20..120 /4.5..27
Nm/lb.
IXFK90N60X Datasheet
