SS5200CF, SS5150CF SCHOTTKY BARRIER RECTIFIERS

SS5200CF Description

Schottky Barrier Rectifiers Production specification SS3150CF *SS3200CF .

SS5200CF Features

* Metal silicon junction, majority carrier conduction
* High surge capability
* High temperature soldering guaranteed: 260°C/10 seconds
* High current capability, low forward voltage drop
* Guarding for over voltage protection
* RoHS Compliant Mechanical Data
* Case: SMCF

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: SS5200CF, SS5150CF. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
SS5200CF, SS5150CF
Manufacturer
GME
File Size
370.38 KB
Datasheet
SS5150CF-GME.pdf
Description
SCHOTTKY BARRIER RECTIFIERS
Note
This datasheet PDF includes multiple part numbers: SS5200CF, SS5150CF.
Please refer to the document for exact specifications by model.
