CY7C1261V18 Datasheet - Cypress Semiconductor

CY7C1261V18 1.8V Synchronous Pipelined SRAM

CY7C1261V18 Features

* Separate independent read and write data ports

* Supports concurrent transactions

* 300 MHz to 400 MHz clock for high bandwidth

* 4-Word Burst for reducing address bus frequency

* Double Data Rate (DDR) interfaces on both read and write ports (data transferred at 800 MHz) at 40
