CY7C1143KV18 Datasheet - Cypress Semiconductor

CY7C1143KV18 18-Mbit QDR II+ SRAM Four-Word Burst Architecture

CY7C1143KV18 Features

* Separate independent read and write data ports

* Supports concurrent transactions

* 450-MHz clock for high bandwidth

* Four-word burst for reducing address bus frequency

* Double data rate (DDR) Interfaces on both read and write ports (data transferred at 900 MHz) at 450 MHz
