SN74LS126A, SN74125 - QUADRUPLE BUS BUFFERS

Texas Instruments

SN74LS126A Datasheet Preview — This datasheet PDF includes multiple part numbers: SN74LS126A, SN74125. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	SN74LS126A, SN74125
Manufacturer	Texas Instruments ↗
File Size	1.19 MB
Description	QUADRUPLE BUS BUFFERS
Datasheet	SN74125-etcTI.pdf
Note	This datasheet PDF includes multiple part numbers: SN74LS126A, SN74125. Please refer to the document for exact specifications by model.

SN74LS126A Product details

Description

These bus buffers feature three-state outputs that, when enabled, have the low impedance characteristics of a TTL output with additional drive capability at high logic levels to permit driving heavily loaded bus lines without external pullup resistors.
