Description
The WV3HG264M64EEU is a 2x64Mx64 Double Data Rate DDR2 SDRAM high density SO-DIMM.
This product is under development, is not qualified or characterized and is subject to change or cancellation without notice.
Vendor source control options
Industrial temperature option
Dual Rank RoHS
Features
- 200-pin, dual in-line memory module (SO-DIMM) Fast data transfer rates: PC2-6400.
- , PC2-5300.
- , PC2-4200 and PC2-3200 Utilizes 800.
- , 667.
- , 533 and 400 Mb/s DDR2 SDRAM components VCC = 1.8V ±0.1V VCCSPD = 1.7V to 3.6V JEDEC standard 1.8V I/O (SSTL_18-compatible) Differential data strobe (DQS, DQS#) option Four-bit prefetch architecture DLL to align DQ and DQS transitions with CK Multiple internal device banks for concurrent operation Supports duplicate output strobe (RDQS/RDQS#) Pro.
