RD30EB, RD3.0EB ZENER DIODES

RD30EB Description

RD2.0E~RD200E ZENER DIODES .

RD30EB Features

* DHD (Double Heatsink Diode) Construction
* Vz: Applied E24 standard (RD130E to RD200E: 10 volts step).

RD30EB Applications

* Circuits for Constant Voltage, Constant Current, Waveform clipper, Surge absorber, etc. Absolute Maximum Ratings (Ta = 25 OC) Parameter Power Dissipation Forward Current Reverse Surge Power at t = 10µs Junction Temperature Storage Temperature Range Symbol Ptot IF PRSM Tj TS Value 500 200 100 175

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: RD30EB, RD3.0EB. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
RD30EB, RD3.0EB
Manufacturer
SEMTECH
File Size
594.03 KB
Datasheet
RD3.0EB-SEMTECH.pdf
Description
ZENER DIODES
Note
This datasheet PDF includes multiple part numbers: RD30EB, RD3.0EB.
Please refer to the document for exact specifications by model.
