UPD160032A - 480-OUTPUT TFT-LCD SOURCE DRIVER

Renesas

📥 Download Datasheet

UPD160032A Datasheet Preview — Preview of UPD160032A PDF

Datasheet Details

Part number	UPD160032A
Manufacturer	Renesas
File Size	428.27 KB
Description	480-OUTPUT TFT-LCD SOURCE DRIVER
Datasheet	UPD160032A-Renesas.pdf

UPD160032A Product details

Description

The μ PD160032A is a source driver for TFT-LCD’s that supports the display of 256 gray scales and employs mini-LVDS interface.Which can realize a full-color display of 16,777,216 colors by output of 256 values γ -corrected by an internal D/A converter and 10-by-2 external power modules.Because the output dynamic range is as large as VSS2 + 0.2 V to VDD2 0.2 V, level inversion operation of the LCD’s common electrode is rendered unnecessary.

Features

Differential interface: CLK (1 pair), gray scale data (6 pair).
CMOS interface: STHR(L), R,/L, STB, SB, POL, Vsel1, Vsel2, SRC, ORC, RxBIAS, H_2DOT, MODE1, MODE2.
480 outputs.
Capable of outputting 256 values by means of 10-by-2 external power modules (20 units) and a D/A converter.
Logic power supply voltage (VDD1): 2.7 to 3.6 V.
Driver power supply voltage (VDD2): 10.0 to 16.5 V.
High-speed data transfer: fCLK = 172 MHz MAX. (Inte.
