ISL9V3040D3ST-F085C - N-Channel IGBT

ON Semiconductor

📥 Download Datasheet

ISL9V3040D3ST-F085C Datasheet Preview — Preview of ISL9V3040D3ST-F085C PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	ISL9V3040D3ST-F085C
Manufacturer	ON Semiconductor
File Size	2.41 MB
Description	N-Channel IGBT
Datasheet	ISL9V3040D3ST-F085C-ONSemiconductor.pdf

ISL9V3040D3ST-F085C Product details

Features

SCIS Energy = 300 mJ at TJ = 25°C.
Logic Level Gate Drive.
AEC.
Q101 Qualified and PPAP Capable.
These Devices are Pb.
Free and are RoHS Compliant.
