MT46H8M32LF - Mobile Low-Power DDR SDRAM

Product Overview

Micron Technology

📥 Download Datasheet

MT46H8M32LF Mobile Low-Power DDR SDRAM by Micron Technology - Datasheet Preview — Datasheet preview – MT46H8M32LF

Datasheet Details

Part number	MT46H8M32LF
Manufacturer	Micron Technology
File Size	3.14 MB
Description	Mobile Low-Power DDR SDRAM
Datasheet	MT46H8M32LF Datasheet
Note	This datasheet PDF includes multiple part numbers: MT46H8M32LF, MT46H16M16. Please refer to the document for exact specifications by model.
Additional preview pages of the MT46H8M32LF datasheet.

Product details

Description

of products still under development. Original Document, Preview

Features

VDD = +1.8V ±0.1V, VDDQ = +1.8V ±0.1V.
Bidirectional data strobe per byte of data (DQS).
Internal, pipelined double data rate (DDR) architecture; two data accesses per clock cycle.
Differential clock inputs (CK and CK#).
Commands entered on each positive CK edge.
DQS edge-aligned with data for READs; centeraligned with data for WRITEs.
Four internal banks for concurrent operation.
Data masks (DM) for masking write data.
