XR16V654 - 2.25V TO 3.6V QUAD UART

Exar Corporation

XR16V654 Datasheet Preview — Preview of XR16V654 PDF

Datasheet Details

Part number	XR16V654
Manufacturer	Exar Corporation
File Size	676.32 KB
Description	2.25V TO 3.6V QUAD UART
Datasheet	XR16V654_ExarCorporation.pdf

XR16V654 Product details

Description

The XR16V6541 (V654) is an enhanced quad Universal Asynchronous Receiver and Transmitter (UART) each with 64 bytes of transmit and receive FIFOs, programmable transmit and receive FIFO trigger levels, automatic hardware and software flow control, and data rates of up to 16 Mbps at 4X sampling rate.

Features

Pin-to-pin compatible with ST16C454, ST16C554, TI’s TL16C754B and Philip’s SC16C654B.
Intel or Motorola Data Bus Interface select.
Four independent UART channels.
Register Set Compatible to 16C550 Data rates of up to 16 Mbps 64 Byte Transmit FIFO 64 Byte Receive FIFO with error tags 4 Selectable TX and RX FIFO Trigger Levels Automatic Hardware (RTS/CTS) Flow Control Automatic Software (Xon/Xoff) Flow Contro.
