AD7151 - Capacitance Converter

Product Overview

Analog Devices

Datasheet Details

Part number	AD7151
Manufacturer	Analog Devices
File Size	465.23 KB
Description	Capacitance Converter
Datasheet	AD7151 Datasheet
Additional preview pages of the AD7151 datasheet.

Product details

Description

The AD7151 delivers a complete signal processing solution for capacitive proximity sensors, featuring an ultra-low power converter with fast response time.

Features

Ultra-low power 2.7 V to 3.6 V, 70 μA Response time: 10 ms Adaptive environmental compensation 1 capacitance input channel Sensor capacitance (CSENS) 0 pF up to 13 pF Sensitivity to 1 fF EMC tested 2 modes of operation Standalone with fixed settings Interfaced to a microcontroller for user-defined settings Proximity detection output flag 2-wire serial interface (I2C compatible) Operating temperature.
40°C to +85°C 10-lead MSOP package.
