BCF81 Datasheet NPN General Purpose Transistors

Manufacturer: Kexin Semiconductor

Datasheet Details

Part number	BCF81
Manufacturer	Kexin Semiconductor
File Size	34.98 KB
Description	NPN General Purpose Transistors
Download	BCF81 Download (PDF)

SMD Type TransistIoCrs NPN General Purpose Transistors BCF81.

Low current (max. 100 mA). Low voltage (max. 45 V). +0.1 2.4 -0.1 SOT-23 2.9+0.1 -0.1 0.4+0.1 -0.1 3 1 2 0.95+0.1 -0.1 1.9+0.1 -0.1 Absolute Maximum Ratings Ta = 25 Parameter Symbol Rating Unit Collector-base voltage VCBO 50 V Collector-emitter voltage VCEO 45 V Emitter-base voltage VEBO 5 V Collector current IC 100 mA Peak collector current ICM 200 mA Peak base current IBM 100 mA Total power dissipation.
Ptot 250 mW Storage temperature Tstg -65 to +.
