AO6808 - Dual N-Channel MOSFET

Key Features

  • s.
  • VDS (V) = 20V.
  • ID =6 A (VGS = 4.5V).
  • RDS(ON) ＜ 23mΩ (VGS = 4.5V).
  • RDS(ON) ＜ 25mΩ (VGS = 4V).
  • RDS(ON) ＜ 27mΩ (VGS = 3.1V).
  • RDS(ON) ＜ 30mΩ (VGS = 2.5V).
  • ESD Rating: 2000V HBM ( SOT-23-6 ) 0.4+0.1 -0.1 6 5 4 1 2 3 +0.01 -0.01 +0.2 -0.1 0-0.1 +0.1 0.68 -0.1 +0.2 1.6 -0.1 +0.2 2.8 -0.1 +0.1 1.1 -0.1 MOSFET Unit: mm 0.4 0.55 0.15 +0.02 -0.02 1 S1 4 G2 2 D1/D2 5 D1/D2 3 S2 6 G1.
  • Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Vo.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AO6808 Dual N-Channel MOSFET Alpha & Omega Semiconductors
AO6800 30V Dual N-Channel MOSFET Alpha & Omega Semiconductors
AO6800 Dual N-Channel MOSFET VBsemi
AO6801 Dual P-Channel MOSFET Alpha & Omega Semiconductors
AO6801 Dual P-Channel MOSFET VBsemi

Other Datasheets by Kexin Semiconductor

Part Number Description
AO6800 Dual N-Channel MOSFET
AO6800-HF Dual N-Channel MOSFET
AO6801 Dual P-Channel MOSFET
AO6801A Dual P-Channel MOSFET
AO6801E Dual P-Channel MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SMD Type Dual N-Channel MOSFET AO6808 (KO6808) ■ Features ● VDS (V) = 20V ● ID =6 A (VGS = 4.5V) ● RDS(ON) ＜ 23mΩ (VGS = 4.5V) ● RDS(ON) ＜ 25mΩ (VGS = 4V) ● RDS(ON) ＜ 27mΩ (VGS = 3.1V) ● RDS(ON) ＜ 30mΩ (VGS = 2.5V) ● ESD Rating: 2000V HBM ( SOT-23-6 ) 0.4+0.1 -0.1 6 5 4 1 2 3 +0.01 -0.01 +0.2 -0.1 0-0.1 +0.1 0.68 -0.1 +0.2 1.6 -0.1 +0.2 2.8 -0.1 +0.1 1.1 -0.1 MOSFET Unit: mm 0.4 0.55 0.15 +0.02 -0.02 1 S1 4 G2 2 D1/D2 5 D1/D2 3 S2 6 G1 ■ Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Voltage Gate-Source Voltage Continuous Drain Current Pulsed Drain Current TA=25℃ TA=70℃ Power Dissipation TA=25℃ TA=70℃ Thermal Resistance.Junction- to-Ambient Thermal Resistance.
