LM98722 - 45 MSPS Analog Front-End

Texas Instruments

The LM98722 by Texas Instruments is a 45 MSPS Analog Front-End. Below is the official datasheet preview.

📥 Download Datasheet

LM98722 45 MSPS Analog Front-End by Texas Instruments - Datasheet Preview — Official preview page of the **LM98722** 45 MSPS Analog Front-End datasheet (Texas Instruments).

Datasheet Details

Part number	LM98722
Manufacturer	Texas Instruments
File Size	5.68 MB
Description	45 MSPS Analog Front-End
Datasheet	LM98722-etcTI.pdf
Additional preview pages of the LM98722 datasheet.

LM98722 Product details

Description

The LM98722 is a fully integrated, high performance 16-Bit, 45 MSPS signal processing solution for digital color copiers, scanners, and other image processing applications.

Features

1 LVDS/CMOS Outputs.
LVDS/CMOS/Crystal Clock Source with PLL Multiplication.
Integrated Flexible Spread Spectrum Clock Generation.
CDS or S/H Processing for CCD or CIS sensors.
Independent Gain/Offset Correction for Each Channel.
Automatic per-Channel Gain and Offset Calibration.
Programmable Input Clamp Voltage.
Flexible CCD/CIS Sensor Timing Generator 2.
