XC9536, XC9536 In-System Programmable CPLD

The XC9536 is a high-performance CPLD providing advanced in-system programming and test capabilities for general purpose logic integration.

It is comprised of two 36V18 Function Blocks, providing 800 usable gates with propagation delays of 5 ns.

See Figure 2 for the architecture overview.

0 50 Clock

XC9536 Features

* 5 ns pin-to-pin logic delays on all pins fCNT to 100 MHz 36 macrocells with 800 usable gates Up to 34 user I/O pins 5 V in-system programmable (ISP) - Endurance of 10,000 program/erase cycles - Program/erase over full commercial voltage and temperatu
