XC9510 Synchronous Step-Down DC/DC Converter

XC9510 Description

XC9510 Series Preliminary ! Input Voltage Range ! Output Voltage Range 2.4V ~ 6.0V DC/DC VR VD 0.9 ~ 4.0V ( ±2%) 0.9 ~ 4.0V (±2%) 0.9 ~ 5.0V (±2%) 800.
The XC9510 series consists of a step-down DC/DC converter and a high-speed LDO regulator connected in series with the DC/DC converter's output.

XC9510 Features

* Input Voltage Range : Load Capacitors : 2.4V ~ 6.0V Ceramic Capacitors Compatible (Low ESR Capacitors) VD Function : Detects output voltage from the VDOUT pin while sensing either VDD, DCOUT, or VROUT internally. Nch Open Drain Output Output Voltage Range : 0.9 ~ 4.0V (Accuracy ±2
