B1118 2SB1118

B1118 Description

Ordering number:1784B PNP/NPN Epitaxial Planar Silicon Transistors 2SB1118/2SD1618 Low-Voltage High-Current Amplifier, Muting Applications .

B1118 Features

* Low collector-to-emitter saturation voltage.
* Very small size making it easy to provide high- density, small-sized hybrid IC’s. Package Dimensions unit:mm 2038 [2SB1118/2SD1618] ( ) : 2SB1118 Specifications Absolute Maximum Ratings at Ta = 25˚C Parameter Collector-to-Base Voltage Col

📥 Download Datasheet

Preview of B1118 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
B1118
Manufacturer
Sanyo
File Size
114.45 KB
Datasheet
B1118-Sanyo.pdf
Description
2SB1118
