2SC3176 - NPN Epitaxial Planar Silicon Transistor

Features

  • Fast switching speed.
  • Especially suited for use in high-definition CRT display (VCC=12 to 24V).
  • Wide ASO. Package Dimensions unit:mm 2010C [2SC3176] Specifications JEDEC : TO-220AB EIAJ : SC46 1 : Base 2 : Collector 3 : Emitter Absolute Maximum Ratings at Ta = 25˚C Parameter Collector-to-Base Voltage Collector-to-Emitter Voltage Emitter-to-Base Voltage Collector Current Collector Current (Pulse) Base Current Collector Dissipation Junction Temperature Storage Temperature.
