2SK1183 Datasheet (Sanken electric)

2SK1183, MOSFET

2SK1183 Absolute Maximum Ratings Symbol VDSS VGSS ID ID (pulse) PD EAS Tch Tstg Ratings 200 ± 20 ±3 ± 12 (Tch 150ºC) (Ta = 25ºC) External dimensions 1 FM20 Electrical Characteristics Symbol V(BR) DSS I GSS I DSS VTH Re (yfs) RDS (on) Ciss Coss t on t off 2.0 0.8 1.2 1.2 140 42 35 50 1.5 min 200 ± 500 250 4.0 Ratings typ max Unit V nA µA V S Ω pF pF ns ns (Ta = 25ºC) Unit V V A A W mJ ºC ºC Conditions I D = 250µA, VGS = 0V VGS = ± 20V VDS = 200V, VGS = 0V VDS = 10V, I D = 250µA VDS = 10
