The K4Y54084UF by Samsung Semiconductor is a XDR/RDRAM. Below is the official datasheet preview.
| Part number | K4Y54084UF |
|---|---|
| Manufacturer | Samsung Semiconductor |
| File Size | 3.45 MB |
| Description | XDR/RDRAM |
| Datasheet |
 K4Y54084UF_SamsungSemiconductor.pdf
|
|
|
XDR DRAM The timing diagrams in Figure 1 illustrate XDR DRAM device write and read transactions.There are three sets of pins used for normal memory access transactions: CFM/CFMN clock pins, RQ11..0 request pins, and DQ15..0/DQN15..0 data pins.The “N” appended to a signal name denotes the complementary signal of a differential pair.A transaction is a collection of packets needed to complete a memory access.A packet is a set of bit windows on the signals of a bus.There are two buses that ca
