Description

The ESDAxxxP6 are monolithic arrays designed to protect up to 5 lines against ESD transients.

Features

4 / 5 unidirectional (ESDA6V1P6 and ESDA6V1-5P6) and bidirectional (ESDA14V2BP6 and ESDA25-4BP6) Transil functions.
Breakdown voltage:.
VBR = 6.1 V min. , 14.2 V min. and 25 V min.
Low leakage current:.
< 500 nA (ESDA6V1P6 / ESDA6V1-5P6).
< 1 μA (ESDA14V2BP6 and ESDA25-4BP6).
Very small PCB area < 2.6 mm2.
Benefits:.
High ESD protection level.
High integration.
Suitable for high density boards.
