MA4160 Silicon planar type

MA4160 Description

Zener Diodes MAZ4000 Series Silicon planar type Unit : mm For stabilization of power supply I .

MA4160 Features

* High reliability, achieved by the DHD structure
* Allowing to insert to a 5 mm pitch hole
* Finely divided zener-voltage rank
* Sharp rising performance
* Wide voltage range: VZ = 2.0 V to 39 V φ 0.45 max. 1 13 min. Colored band indicates Vz classification

📥 Download Datasheet

Preview of MA4160 PDF
datasheet Preview Page 2 datasheet Preview Page 3
