CAT6218 - 300 mA CMOS LDO Regulator

ON Semiconductor

📥 Download Datasheet

CAT6218 Datasheet Preview — Preview of CAT6218 PDF

Datasheet Details

Part number	CAT6218
Manufacturer	ON Semiconductor
File Size	310.92 KB
Description	300 mA CMOS LDO Regulator
Datasheet	CAT6218_ONSemiconductor.pdf

CAT6218 Product details

Description

The CAT6218 is a 300 mA CMOS low dropout regulator that provides fast response time during load current and line voltage changes. start feature allows the use of an external bypass capacitor to reduce the overall output noise without affecting the turn on time of just 150 ms. operated devices with supply voltages from 2.3 V to 5.5 V.

Features

include fold.
back current limit and thermal protection. The device is available in the low profile (1 mm max height) 5.
lead thin SOT23 package. Features.
Guaranteed 300 mA Output Current.
Low Dropout Voltage of 180 mV Typical at 300 mA.
Stable with 1 mF Ceramic Output Capacitor.
External 10 nF Bypass Capacitor for Low Noise.
Quick.
start Feature.
No.
load Ground Current of 55 mA Typical.
Full.
loa.
