CAT6202 - CMOS LDO Regulator

Name: CAT6202
SKU: CAT6202-755018

ON Semiconductor

📥 Download Datasheet

CAT6202 Datasheet Preview — Preview of CAT6202 PDF

Datasheet Details

Part number	CAT6202
Manufacturer	ON Semiconductor
File Size	312.64 KB
Description	CMOS LDO Regulator
Datasheet	CAT6202_ONSemiconductor.pdf

CAT6202 Product details

Description

The CAT6202 is a 13 V rated 500 mA CMOS low dropout regulator that provides fast response time to load current and line voltage changes in an automotive environment.

Features

a low RON P.
channel pass element with internal control circuitry which prevents reverse current flow should the voltage at VOUT exceed VIN as in the case of the car’s battery voltage accidentally being applied to VOUT. Thermal protection and current limiting circuitry combine to protect the pass device against faults and abuse. Current limiting is user controlled through a single resistor to ground. A fault output (FLT) provides an alert should an over.
current event or thermal sh.
