R1171S - 2.0A/1.5A LDO REGULATOR

Nisshinbo

📥 Download Datasheet

R1171S Datasheet Preview — Preview of R1171S PDF

Datasheet Details

Part number	R1171S
Manufacturer	Nisshinbo
File Size	631.62 KB
Description	2.0A/1.5A LDO REGULATOR
Datasheet	R1171S-Nisshinbo.pdf

R1171S Product details

Description

HSOP-6J Pin No Symbol 1 VOUT 2 GND 3 CE or CE 4 NC 5 GND 6 VDD Output Pin Ground Pin Chip Enable Pin No Connection Ground Pin Input Pin Pin Description TO-252-5-P1 Pin No 1 Symbol VOUT Output Pin Pin Description 2 CE or CE Chip Enable Pin 3 GND Ground Pin 4 GND Ground Pin 5 VDD Input Pin ∗) No.3 and No.4 pins must be wired short each other and connected to the GND plane when it is mounted on board.3 R1171J (TO-252-5) is the discontin

Features

of low dropout voltage, high output voltage accuracy, low consumption current. Each of these ICs consists of a voltage reference unit, an error amplifier, resistor net for setting output voltage, a current limit circuit at short mode, a chip enable circuit, and thermal shutdown circuit. The output voltage of R1171 is fixed in the IC. Low consumption current by the merit of CMOS process and built-in transistors with low ON-resistance make low dropout voltage and chip enable function prolongs the.
