UPD2114L-1, UPD2114L - 4K-Bit Static RAM

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: UPD2114L-1, UPD2114L. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number UPD2114L-1, UPD2114L
Manufacturer NEC
File Size 239.39 KB
Description 4K-Bit Static RAM
Datasheet download datasheet UPD2114L_NEC.pdf
Note This datasheet PDF includes multiple part numbers: UPD2114L-1, UPD2114L.
Please refer to the document for exact specifications by model.

UPD2114L-1 Product details

Description

4098 BIT (1024 )( 4 BITS) STATIC RAM The NEC I.lPD2114L is a 4096 bit static Random Access Memory organized as 1024 words by 4 bits using N-channeISilicon-gate MOS technology_ It uses fully DC stable (static) circuitry throughout, in both the array and the decoding_ It therefore requires no clocks or refreshing to operate and simplifies system design.The data is read out nondestructively and has the same polarity as the input data_ Common input/output pins are provided.II The I.lPD2114L is
