MAX8761 - Low-Cost Linear-Regulator LCD Panel Power Supplies

Product Overview

Maxim Integrated Products

Part number	MAX8761
Manufacturer	Maxim Integrated Products
File Size	658.26 KB
Description	Low-Cost Linear-Regulator LCD Panel Power Supplies
Datasheet	MAX8761 Datasheet
Note	This datasheet PDF includes multiple part numbers: MAX8761, MAX8710. Please refer to the document for exact specifications by model.
Additional preview pages of the MAX8761 datasheet.

High-Performance Linear Regulator 1.6% Output Accuracy Works with Small Ceramic Output Capacitors Fast Transient Response Foldback Current Limit.
50mA Negative Regulated Charge Pump.
20mA Positive Regulated Charge Pump with Adjustable Delay.
Built-In Power-Up Sequence.
High-Current Operational Amplifier (MAX8710/MAX8711/MAX8761) ±150mA Output Short-Circuit Current 12V/µs Slew Rate 12MHz, -3dB Bandwidth Rail-to-Rail Inputs/Output.
Dual-Mode™.
