LTV-480P-TA, LTV-480W-LITE - OPTOCOUPLER

LITE-ON

LTV-480P-TA Datasheet Preview — This datasheet PDF includes multiple part numbers: LTV-480P-TA, LTV-480W-LITE. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	LTV-480P-TA, LTV-480W-LITE
Manufacturer	LITEON ↗
File Size	718.61 KB
Description	OPTOCOUPLER
Datasheet	LTV-480W-LITE-ON.pdf
Note	This datasheet PDF includes multiple part numbers: LTV-480P-TA, LTV-480W-LITE. Please refer to the document for exact specifications by model.

LTV-480P-TA Product details

Description

The LTV-480 series fast speed photocoupler contains a AlGaAs LED and photo detector with built-in Schmitt trigger to provide logic-compatible waveforms, eliminating the need for additional wave shaping.

Features

Positive output type (totem pole output).
Truth Table Guaranteed: VCC from 4.5V to 30V.
Performance Specified for Common IPM.
