ICS9DB102 - 2 Output PCI Express Buffer

Integrated Circuit Systems

📥 Download Datasheet

ICS9DB102 Datasheet Preview — Preview of ICS9DB102 PDF

Datasheet Details

Part number	ICS9DB102
Manufacturer	Integrated Circuit Systems
File Size	275.87 KB
Description	2 Output PCI Express Buffer
Datasheet	ICS9DB102_IntegratedCircuitSystems.pdf

ICS9DB102 Product details

Description

PIN # 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 PLL_BW CLK_INT CLK_INC CLKREQ0# VDD GND PCIEXT0 PCIEXC0 VDD SMBDAT SMBCLK VDD PCIEXC1 PCIEXT1 GND VDD CLKREQ1# PIN NAME PIN TYPE IN IN IN IN PWR PWR OUT OUT PWR I/O IN PWR OUT OUT PWR PWR IN DESCRIPTION 3.3V input for selecting PLL Band Width 0 = low, 1= high "True" reference clock input.

Features

2 - 0.7V current mode differential output pairs (HSCL) Key Specifications:.
Cycle-to-cycle jitter < 35ps.
Output-to-output skew < 25 ps Features/Benefits:.
CLKREQ# pin for outputs 1 and 4/output enable for Express Card.
