TLE49SR Product details

Description

The TLE49SR is a stray field robust angle sensor based on Hall technology for measuring absolute angular position in the range from 0° to 360°.

Features

Intrinsic stray field robustness.
Differential Hall based angle sensor.
360° angle measurement.
Angle speed information.
PWM, SPC, SENT (based on SAE J2716-2016) interfaces.
SMD package.
Max. +/-1° intrinsic angle error over lifetime and temperature range.
High voltage and reverse polarity capability.
14 bit over 360° representation of absolute angle value on the output.
EEPROM for storage of configuration.
