ICMEF212P900MFR - COMMON MODE ESD FILTER

ICMEF212P900MFR Datasheet Preview — Preview of ICMEF212P900MFR PDF

Datasheet Details

Part number	ICMEF212P900MFR
Manufacturer	INNOCHIPS TECHNOLOGY
File Size	742.07 KB
Description	COMMON MODE ESD FILTER
Datasheet	ICMEF212P900MFR-INNOCHIPSTECHNOLOGY.pdf

ICMEF212P900MFR Product details

Description

Operating Temperature REQUIREMENTS -40℃ ∼ + 85℃ Page 4 5. 5. Equivalent Circuit & Recommended Foot print & Stencil mask PIN NUMBER ①~④ ⑤, ⑥ DESCRIPTION DATA LINE GROUND Unit : mm Stencil Mask T : 0.10mm ①② ⑤ ⑥ ③④ [ Equivalent circuit ] [ Foot print ] 6. Mechanical Property 6. 1 Appearance and Dimension [ Stencil Mask ] Unit : mm ITEM COMMON MODE ESD FILTER P/N ICMEF212P900MFR 7. TEST METHOD OF ELECTRICAL PROPERTY Page 5 - PIN INDEX Pin1 Pin6 Pin3 Pin2 Pin5

Features

Effective for suppressing common mode noise and almost no effect for high speed differential data line.
One common mode filters and two ESD suppression devices integrated.
Ultra low profile (2.0ⅹ1.2ⅹ0.8mm).
Ceramic multilayer type SMD component.
Non-polarized product.
It is a product conforming to RoHS directive. 3.
