MRF8P23080HR3 - RF Power Field Effect Transistors

Freescale Semiconductor

📥 Download Datasheet

MRF8P23080HR3 Datasheet Preview — Preview of MRF8P23080HR3 PDF

Datasheet Details

Part number	MRF8P23080HR3
Manufacturer	Freescale Semiconductor
File Size	690.62 KB
Description	RF Power Field Effect Transistors
Datasheet	MRF8P23080HR3_FreescaleSemiconductor.pdf

MRF8P23080HR3 Product details

Description

0.8 pF Chip Capacitors 1.0 pF Chip Capacitors 18 pF Chip Capacitors 8.2 pF Chip Capacitors 1.0 μF, 50 V Chip Capacitors 10 pF Chip Capacitors 5.6 pF Chip Capacitors 10 μF, 50 V Chip Capacitors 470 μF, 63 V Electrolytic Capacitors 50 Ω, 1/4 W Chip Resistor 2500 MHz Band 90°, 3 dB Chip Hybrid Coupler 0.020″, εr = 3.5 Part Number ATC600F0R8JT250XT ATC600F1R0JT250XT ATC600F180JT250XT ATC600F8R2JT250XT GRM21BR71H105KA12L ATC600F100JT250XT ATC600F5R6JT250XT GRM55DR61H106KA88L MCGPR63V477M13X26--RH CRC

Features

Production Tested in a Symmetrical Doherty Configuration.
100% PAR Tested for Guaranteed Output Power Capability.
Characterized with Large--Signal Load--Pull Parameters and Common Source S--Parameters.
Internally Matched for Ease of Use.
Integrated ESD Protection.
Greater Negative Gate--Source Voltage Range for Improved Class C Operation.
Designed for Digital Predistortion Error Correction Systems.
RoHS Compliant.
