NM27C010 - 1 /048 /576-Bit (128K x 8) High Performance CMOS EPROM

Fairchild

Datasheet Details

The NM27C010 is a high performance, 1,048,576-bit Electrically Programmable UV Erasable Read Only Memory.

s High performance CMOS.
70 ns access time s Fast turn-off for microprocessor compatibility s Simplified upgrade path.
VPP and PGM are “Don’t Care” during normal read operation s Manufacturers identification code s Fast programming s JEDEC standard pin configurations.
32-pin PDIP package.
32-pin PLCC package.
32-pin CERDIP package Block Diagram VCC GND VPP OE CE PGM Output Enable, Chip Enable, and Program Logic Data Outputs O0 - O7 Output Buffers.
