DM9328 - Dual 8-Bit Shift Register

Fairchild Semiconductor

Datasheet Details

Part number	DM9328
Manufacturer	Fairchild Semiconductor
File Size	220.11 KB
Description	Dual 8-Bit Shift Register
Datasheet	DM9328_FairchildSemiconductor.pdf

The DM9328 is a high speed serial storage element providing 16 bits of storage in the form of two 8-bit registers.

1) additional gating is provided at the input to both shift registers so that the input is easily multiplexed between two sources; 2) the clock of each register may be provided separately or together; 3) both the true and complementary outputs are provided from each 8-bit register, and both registers may be master cleared from a common input. Ordering Code: Order Number DM9328N Package Number N16E Package.
