STU6010 SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

STU6010 Description

STU606I - STU65G4 VBR : 6.8 - 440 Volts PPK : 600 Watts .

STU6010 Features

* : www. DataSheet4U. com
* 600W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR SMB (DO-214AA) 1.1 ± 0.3 5.4 ± 0.15 surge capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time : typically less then 1.0 ps from 0 volt to VBR(min. )
* Typical IR les

STU6010 Applications

* For bi-directional altered the third letter of type from "U" to be "B". Electrical characteristics apply in both directions MAXIMUM RATINGS Rating at 25 °C ambient temperature unless otherwise specified. Rating Peak Power Dissipation at Ta = 25 °C, Tp=1ms (Note1) Steady State Power Dissipation at

📥 Download Datasheet

Preview of STU6010 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
STU6010
Manufacturer
EIC discrete Semiconductors
File Size
63.77 KB
Datasheet
STU6010_EICdiscreteSemiconductors.pdf
Description
SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
