2A06G Features
* Glass Passivated Die Construction
* High Current Capability and Low Forward Voltage Drop
* Surge Overload Rating to 65A Peak
* Lead Free Finish, RoHS Compliant (Note 3)
Mechanical Data
* Case: DO-15
* Case Material: Molded Plastic. UL Flammability Cl
2A06G Applications
* shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or syst
