2A02G, 2A01G - 2.0A GLASS PASSIVATED RECTIFIER

DIODES

The 2A02G by DIODES is a 2.0A GLASS PASSIVATED RECTIFIER. Below is the official datasheet preview.

📥 Download Datasheet

2A02G 2.0A GLASS PASSIVATED RECTIFIER by DIODES - Datasheet Preview — Official preview page of the 2A02G 2.0A GLASS PASSIVATED RECTIFIER datasheet (DIODES).

Datasheet Details

Part number	2A02G, 2A01G
Manufacturer	DIODES
File Size	126.95 KB
Description	2.0A GLASS PASSIVATED RECTIFIER
Datasheet	2A01G-DIODES.pdf
Note	This datasheet PDF includes multiple part numbers: 2A02G, 2A01G. Please refer to the document for exact specifications by model.
Additional preview pages of the 2A02G datasheet.

2A02G Product details

Features

Glass Passivated Die Construction.
High Current Capability and Low Forward Voltage Drop.
Surge Overload Rating to 65A Peak.
Lead Free Finish, RoHS Compliant (Note 3) Mechanical Data.
Case: DO-15.
Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0.
Moisture Sensitivity: Level 1 per J-STD-020C.
Terminals: Finish.
Tin. Solderable per MIL-STD-202, Method 208.
Polarity: Cathode Band.
