MX105A Tone Detector

MX105A Description

DATA BULLETIN MX105A Tone Detector * .

MX105A Features

* Operates in High Noise Conditions
* ≥36 dB Signal Input Range
* High Sensitivity
* Low Power Operation 2.7 V to 5.5 V
* Adjustable Bandwidth
* Adjustable Frequency PRELIMINARY INFORMATION

MX105A Applications

* Single and Multitone System Applications C4 C2A 7 8 C2B R2 4 Loop Filter -+ Tone In C5 R3 2 Input Amp 1 3 - VDD/2 + Timing Logic Detect Filter -+ VDD 16 5 C3A 6 C3B C6 11 R4 12 VCO Detect Counter 13 15 14 MX105A C1B R1 C1A 10 9 Detect RL Out The MX105A is a monolithic
