Description

OPA830 SBOS263B * AUGUST 2004 * REVISED JANUARY 2005 Low-Power, Single-Supply, Wideband Operational Amplifier .
The OPA830 is a low-power, single-supply, wideband, voltage-feedback amplifier designed to operate on a single +3V or +5V supply.

📥 Download Datasheet

OPA2832 Datasheet Preview — This datasheet PDF includes multiple part numbers: OPA2832, OPA2832_Burr. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: OPA2832, OPA2832_Burr
Manufacturer: Burr-Brown
File Size: 460.31 KB
Datasheet: OPA2832_Burr-BrownCorporation.pdf
Description: Low-Power / Single-Supply / Wideband Operational Amplifier
Note: This datasheet PDF includes multiple part numbers: OPA2832, OPA2832_Burr.
Please refer to the document for exact specifications by model.

Features

* D D D D D D D D HIGH BANDWIDTH: 250MHz (G = +1) 110MHz (G = +2) LOW SUPPLY CURRENT: 3.9mA (VS = +5V) FLEXIBLE SUPPLY RANGE: ±1.4V to ±5.5V Dual Supply +2.8V to +11V Single Supply INPUT RANGE INCLUDES GROUND ON SINGLE SUPPLY 4.88V OUTPUT SWING ON +5V SUPPLY HIGH SLEW RATE: 550V/ns LOW INPUT VOLTAGE N
