Part number:
HM4616D
Manufacturer:
H&M Semiconductor
File Size:
969.62 KB
Description:
N and p-channel enhancement mode mosfet.
Datasheet Details
HM4616D Features
* N-channel： VDS =30V,ID =35A RDS(ON)=5.5mΩ (typical) @ VGS=10V RDS(ON)=7.8mΩ (typical) @ VGS=4.5V P-Channel： VDS =-30V,ID =-18A RDS(ON)=15mΩ (typical) @ VGS=-10V RDS(ON)=20mΩ (typical) @ VGS=-4.5V
* Excellent gate charge x RDS(ON) product(FOM)
* Very low on-resistance RDS(ON)
* 1
Datasheet Details
HM4616D
H&M Semiconductor
969.62 KB
N and p-channel enhancement mode mosfet.
