PE24111 - 20A Two-stage Buck Regulator

General Description

The PE24111 is a compact, low-profile, and ultrahigh efficiency step-down DC-DC converter solution capable of delivering 20A output current from an input voltage range from 3.0

3.6V.

Key Features

  • Proprietary architecture enabling industryleading efficiency with ultra-low profile and footprint.
  • 90% peak efficiency.
  • Wide input voltage range, from 3.0.
  • 3.6V, that supports running off a nominal 3.3V bus supply.
  • Output voltage regulation accuracy better than ±1% for all line and load variations.
  • Output voltage set by external feedback resistors.
  • Output can be adjusted by an external AVS DAC.
  • External sync pin allows synchronization to an external clo.

📥 Download Datasheet

Datasheet Details

Part number PE24111
Manufacturer pSemi
File Size 3.75 MB
Description 20A Two-stage Buck Regulator
Datasheet download datasheet PE24111 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
PE240128WRF-001-HC1Q LCD POWERTIP
PE240128WRF001HC1Q LCD POWERTIP
PE24064WRM-004-I-Q LCD Module POWERTIP
PE200GB THYRISTOR MODULE SanRex Corporation
PE2010 CURRENT SENSOR YAGEO

Other Datasheets by pSemi

Part Number Description
PE24108 Two-stage Buck Regulator
PE23108 High-Efficiency LED Backlight Driver
PE25200 10A Charge Pump / Capacitor Divider
PE25204 6A Charge Pump / Capacitor Divider
PE25213 10A Charge Pump / Capacitor Divider

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
PE24111 Document Category: Product Specification 3.3 VIN, 20A, Two-stage Buck Regulator for Low Output Voltage Applications General Description The PE24111 is a compact, low-profile, and ultrahigh efficiency step-down DC-DC converter solution capable of delivering 20A output current from an input voltage range from 3.0–3.6V. The output voltage is set between 0.35V and 0.7V with external feedback resistors and can be adjusted by an external AVS DAC. Based on pSemi advanced two-stage architecture, the PE24111 consists of a two-phase interleaved charge pump followed by an interleaved buck regulator stage. This power system greatly reduces the inductance necessary for high efficiency while maintaining a small solution size for small-footprint and heightconstrained applications.
