AO6802 - Dual 30V N-ChanneI MOSFET

General Description

The AO6802 uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

This device is suitable for use as a load switch or in PWM applications.

AO6802 dual 30v n-channei mosfet by UMW - Datasheet Preview

Datasheet Details

Part number	AO6802
Manufacturer	UMW
File Size	258.06 KB
Description	Dual 30V N-ChanneI MOSFET
Datasheet	AO6802 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
AO6802	Dual N-Channel MOSFET	Kexin
AO6802	N-Channel MOSFET	Freescale
AO6802	30V Dual N-Channel MOSFET	Alpha & Omega Semiconductors
AO6800	30V Dual N-Channel MOSFET	Alpha & Omega Semiconductors
AO6800	Dual N-Channel MOSFET	Kexin

Other Datasheets by UMW

Part Number	Description

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

UMW AO6802 Dual 30V N-ChanneI MOSFET 1.Description The AO6802 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. This device is suitable for use as a load switch or in PWM applications. 2.Product Summary VDS (V)=30V RDS(ON)<40mΩ(VGS=10V) RDS(ON)<55mΩ(VGS=4.5V) 3.Pinning information Pin Symbol Description 1,3 G1, G2 GATE 5,2 S1, S2 SOURCE 6,4 D1, D2 DRAIN D1 D2 G1 1 6 D1 S2 2 5 S1 G2 3 4 D2 G1 G2 S1 S2 SOT23-6 4.Absolute Maximum Ratings TA= 25°C Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current Pulsed Drain Current C Power Dissipation B Junction and Storage Temperature Range TA=25°C TA=70°C TA=25°C TA=70°C Symbol VDS VGS ID IDM PD TJ, TSTG Maximum 30 ±20 3.5 3 20 1.15 0.
